Swarovski EL Range 10x42 TA Green Binocular (with Tracking Assistant)
)
The EL RANGE is the latest demonstration of the innovativeness that lies at the heart of SWAROVSKI OPTIK. It combines SWAROVISION technology with precise range measurement. Spot game quickly and accurately thanks to the precision and edge-to-edge sharpness of SWAROVISION technology.
The EL Range can be configured to suit your specific needs and you can transfer your own ballistics data, along with air pressure and temperature readings, allowing you to make an accurate assessment of every hunting situation. The innovative tracking assistant helps you to narrow down the area where your last shot hit the target.
Uncompromising observation. The EL Range 10x42 shows precise details when viewing over long distances thanks to its 10x magnification.
Scope of delivery
- FSB functional sidebag
- UCS-R universal comfort strap with battery compartment
- Eyepiece cover
- Objective lens cover
- BT tool
- Soap & Brush
EL Range 42
GROUND-BREAKING PRECISION
The EL Range can be configured to suit your specific needs and you can transfer your own ballistics data, allowing you to make an accurate assessment of every hunting situation. The EL Range 42 is a perfect all-rounder at any time of day.
EL Range 32
GROUND-BREAKINGLY LIGHT
Weighing less than 700 grams (25 ounces), the EL Range 32 is a rugged companion on challenging hunting tours and will help you to ensure an ethical and precise shot in every situation.
EL RANGE 32
LIGHTWEIGHT, COMPACT EXPERTISE
Weighing less than 700 grams (25 ounces), the EL Range 32 is a rugged companion on challenging hunting tours and will help you to ensure an ethical and precise shot in every situation.
SMART COMPANION
The rangefinder and customizable configuration allow you to adapt the EL Range perfectly to your needs. The Tracking Assistant also helps you to narrow down the area where you took your last shot.
EXCEPTIONAL DETAILS
High-contrast images with natural colors and razor-sharp contours: the EL Range impresses with perfect optics in a compact design.
EL RANGE 42
ALL-WAYS PRECISE
The EL Range can be configured to suit your specific needs and you can transfer your own ballistics data, allowing you to make an accurate assessment of every hunting situation.
FOCUS ON PERFECTION
In every hunting scenario, you can spot game quickly and accurately thanks to the precision and edge-to-edge sharpness of SWAROVISION technology.
TRAIL-BLAZING INTELLIGENCE
The innovative tracking assistant helps you to narrow down the area where your last shot hit the target.
THE EL RANGE 42 AND EL RANGE 32 BINOCULARS COMBINE ON-POINT OPTICAL QUALITY WITH DIGITAL INTELLIGENCE.
RANGEFINDER
MEASURE
The binoculars combine state-of-the-art optics with precise measuring functions.
The integrated tilt indicator with a unique angle shot program displays either the adjusted shooting distance or the angle. The EL RANGE gives you precise measurements from a distance of 10 meters (10.9 yards).
PERSONALIZED BALLISTICS
AIM
Use the smartphone app to configure the binoculars to your specific needs and individual ballistics data. Based on this and atmospheric data such as air pressure and temperature, it helps you to shoot with even greater precision because, along with the adjusted shooting distance, it also gives you the number of clicks needed for your rifle scope.
TRACKING ASSISTANT
FIND
The integrated Tracking Assistant makes it much easier to track your prey by guiding you to where you fired your last shot. You can opt to use this program via your phone or your EL Range.
SWAROVSKI OPTIK
EL RANGE CONFIGURATOR APP
It’s easy to customize your EL Range with Tracking Assistant. Transfer your personal ballistics data of your SWAROVSKI OPTIK rifle scope directly via the app, and you can even use it on your smartphone.
| Color | orange & green |
|---|---|
| OBJECTIVE | |
| Magnification | 10x |
| Effective objective lens diameter | 42mm |
| Exit pupil diameter | 4.2mm |
| exit-pupil-distance-eye-relief-mm | 19mm |
| Field of view m at 1000m / ft at 1,000yds | 120 m/1000m |
| Field of view degrees | 6.8 |
| Field of view with eye glasses (°) | 6.8 |
| Field of view apparent | 61 |
| Shortest focusing distance | 5m |
| Diopter adjustment | +/- 5dpt |
| Light transmission | 90% |
| Pupil distance | 56-74mm |
| Twilight factor acc. to DIN-58388 | 20.5 |
| SIZE & WEIGHT | |
| Length in mm. | 169 mm |
| Width in mm. | 136 mm |
| Height in mm. | 79 mm |
| Weight without batteries | 925 g |
| ENVIRONMENT & CONDITIONS | |
| functional-temperature-mechanically-electronically | -25 to +55 / -10 to +55 °C |
| MEASUREMENT | |
| Measuring range in yds./ m. | 10 - 2000 m |
| Measuring accuracy in yds./ m. | 1 m |
| Measuring time | <0.5 s |
| Angular measurement | 90 ° |
| Laser | Class 1 EN/FDA |
| Units | Yard / Meter |
| Life cycle | 2,000 measurements |
| DIGITAL | |
| Battery | CR2 |
What are SWAROVSKI OPTIK's warranty terms?
The duration and scope of the manufacturer’s warranty depend on the product, the production year, and the components used.
This is how you determine when your device was made: What is the year of manufacture of my device?
The diagram below provides an overview:
This means for example:
- for products without electronics produced after 2007 (e. g. NL Pure), SWAROVSKI OPTIK covers the costs for labor and material for 10 years (5 years manufacturer's warranty, 5 years goodwill) in case of a warranty repair
- for products without electronics produced before 2007 (e. g. AT 80), SWAROVSKI OPTIK covers the costs for labor and material for 10 years and the costs for material for 20 more years in case of a warranty repair
- for products with electronics (e. g. EL Range), SWAROVSKI OPTIK covers in case of a warranty repair
- costs for labor and material for 5 years (2 years warranty, 3 years goodwill) for electronics
- costs for labor and material for 10 years (5 years manufacturer's warranty, 5 years goodwill) for optics and mechanics.
- Accessories and Gear are covered by the 2-year statutory guarantee.
- Extendable spotting scopes (CTC/CTS) have a 5-year warranty.
- A 3-year warranty is granted for products with essential electronics (tM 35).
- Please note the warranty terms enclosed with the product.
For a warranty repair, a warranty/service document or proof of purchase is needed.
You find the detailed applying warranty terms in your manual or on our website, on the product's page when you click on “Warranty”. The enclosed document gives a more thorough insight in our general warranty terms.
